LD-T390 Skid Steer Loader: Redefining Operational Paradigms with Exceptional Performance

In modern engineering and logistics operations, the demand for equipment that balances efficiency, flexibility, and versatility has never been greater. The LD-T390 Skid Steer Loader meets these challenges head-on, delivering innovative solutions for narrow-space tasks and diverse construction needs through its refined core performance, precise control, and adaptable configurations.

I. Diverse Power Options for Precise Adaptation

The LD-T390 excels in power versatility, offering engine options from electric, Koop, Runtong, Zhongcheng, and B&S, with power outputs ranging from 6–9.9 kW.

The electric version features a 72V/125Ah battery, providing zero emissions and ultra-quiet operation—ideal for indoor environments, warehouses, and noise-sensitive zones.

Fuel-powered engines deliver robust performance for heavy-duty outdoor tasks like earthworks and agricultural handling, ensuring optimal power delivery across all scenarios.

II. Robust Loading Capacity for High-Efficiency Operations

The LD-T390’s loading performance is designed for productivity:

Rated operating capacity: 200 kg; maximum operating capacity: 300 kg, enabling seamless handling of both daily materials and heavy loads.

With a 3.5 kN breakout force and 0.12 m³ bucket capacity, it effortlessly excavates and loads dense materials, significantly enhancing operational efficiency.

III. Compact Design for Universal Maneuverability

Thanks to its sleek engineering, the LD-T390 navigates tight spaces with ease:

Overall dimensions: Height 1250 mm, width 960 mm, tail length 220 mm—perfect for narrow alleyways, construction sites, and confined municipal environments.

180×72×45 rubber tracks with 1300 mm ground contact length and 230 mm ground clearance ensure stability on flat surfaces and superior traversal of muddy or rugged terrain.

IV. Precision Control for Streamlined Workflows

Advanced technology drives the LD-T390’s operational precision:

9-second total cycle time and 0–6 km/h stepless speed regulation minimize material handling delays, boosting workflow efficiency.

1470 mm dump height and 600 mm dump reach enable precise material placement, while a 2000 mm bucket pin height and 2620 mm maximum lift height accommodate high-altitude tasks.

27° ground-level tilt and 114° high-position tilt angles allow for multi-directional agility, simplifying complex operations like grading and debris removal.

V. Durable Construction and Eco-Compliance

The LD-T390 prioritizes longevity and sustainability:

1070 kg operating weight, reinforced with a high-strength steel frame and 17 bar hydraulic pipelines (treated for wear resistance), ensures durability under continuous heavy use.

Fuel models comply with EPA/EURO5 emissions standards, while the electric version achieves zero emissions, meeting environmental regulations in Europe, North America, and beyond.

A 5L fuel tank (for diesel models) reduces refueling frequency, enhancing operational continuity.

VI. Flexible Configurations for Multi-Task Versatility

The LD-T390 adapts to evolving needs through modular design:

2400 mm standard bucket (1050 mm width) excels in earthmoving; removing the bucket reduces length to 1900 mm for quick switching to attachments like breakers, snow blowers, or pallet forks (sold separately).

Ergonomic features include a wide-view cockpit and intuitive control handles to minimize operator fatigue, while standard LED work lights ensure safe operation in low-light conditions.

The LD-T390 Skid Steer Loader combines cutting-edge performance, adaptability, and reliability, making it the go-to choice for municipal projects, agriculture, logistics, and more. Whether optimizing efficiency in tight spaces or tackling rugged outdoor tasks, the LD-T390 delivers unmatched value. Contact us today to explore customized configurations and elevate your operations!
